Unleash 300 watts of Ashdown bass power in a compact, road-ready head.
The Original-EVO-300 combines a versatile 5-band EQ, effects loop, and XLR DI output with rugged construction.
This makes it the perfect partner for rehearsals, studio sessions, and gigs alike.
Lightweight, reliable, and packed with tone, it's bass excellence you can carry anywhere.
POWER
• Power Output: 300 Watts
• Power Requirements: 115–230 Volts
• Impedance: Minimum 4 Ohms
CONNECTIVITY & I/O
• Speaker Outputs: 2 × Jack outputs
• High Instrument Input: Impedance 3.9M Ohms, input range 150mV – 20V p-p
• Low Instrument Input: Impedance 1M Ohms, input range 150mV – 10V p-p
• Line Input: Impedance 10k Ohms, input range 300mV – 40V p-p
• DI Output: 600 Ohm balanced, Level –20dBu nominal
• Effects Send: Impedance 22k Ohm, Level 0dBu nominal
• Effects Return: Impedance 22k Ohms, Input Level 0dBu nominal
PERFORMANCE
• Frequency Response: –3dB @ 22Hz and 25kHz
• Signal to Noise: Better than 80dB (EQ flat)
• EQ:
• Bass: ±15dB @ 100Hz
• Lo Mid: ±15dB @ 220Hz
• Middle: ±15dB @ 660Hz
• Hi Mid: ±15dB @ 1.6kHz
• Treble: ±15dB @ 7kHz shelving
• Distortion: Less than 0.5% THD
DIMENSIONS & WEIGHT
• Height: 89 mm
• Width: 220 mm
• Depth: 209 mm
• Net Weight: 1.8 kg
